New design High-quality cone crusher with high reputation
| Price: | 1000.0~10000.0 USD |
| Payment Terms: | T/T,L/C,WU |
| Place of Origin: | Henan, China (Mainland) |
|
|
| Add to My Favorites | |
| HiSupplier Escrow |
Product Detail
Model No.:
p
Production Capacity:
100sets/mouth
Delivery Date:
7~15 days after payment
Type:
Crusher
Warranty:
1 year
Means of Transport:
Ocean,Land
Packing:
Export standard
Application:
Ore
Brand Name:
ZHONGCHENG
Detailed Product Description
1. Stable and long span life
2. Easy to adjust
3. Reliable operation.
4. Easy maintenance.
5. No polluti
New design High-quality cone crusher with high reputation
1.Specifications of Spring Cone Crusher
1) High productivity
2)Power saving
3)Large capacity
4)Best after-sales service
2)Power saving
3)Large capacity
4)Best after-sales service
2.Description of Spring Cone Crusher
Cone crusher is the most popular equipment for the large quarry and the mining industry, which is a kind of advanced industrial machinery with the development of the mining technology, and the precision of the new technology is remarkable.
3.Structural Characteristics of Spring Cone Crusher
1. This crushing equipment has compact structure and high productivity. It adopts bowl-shaped bearing which has high precision. Concentrated thin oil lubrication system is also used.
2. The size of the discharge opening can be adjusted by propelling cylinder. When the materials that can not be crushed enter into the crushing chamber, the spring safety device can protect the equipment.
3. This machine adopts grease seal to avoid mixing of water and oil. When sealing parts are worn, spring can help them recover sealing function. When the thickness of sealing part reduced to 1/4-1/3 of the original thickness, users should replace the sealing part.
1. This crushing equipment has compact structure and high productivity. It adopts bowl-shaped bearing which has high precision. Concentrated thin oil lubrication system is also used.
2. The size of the discharge opening can be adjusted by propelling cylinder. When the materials that can not be crushed enter into the crushing chamber, the spring safety device can protect the equipment.
3. This machine adopts grease seal to avoid mixing of water and oil. When sealing parts are worn, spring can help them recover sealing function. When the thickness of sealing part reduced to 1/4-1/3 of the original thickness, users should replace the sealing part.
4.Working Principle of Spring Cone Crusher
1. When cone crusher is working, motor drives the eccentric sleeve to rotate. The eccentric sleeve drives the transmission shaft and cone part to make swing movement. When they swing to the extent that the surface of the crushing wall is close to the roll mortar wall, the rocks and ores are pressed and crushed.
2. Joint between supporting sleeve and frame is compressed by spring. When metal block and other materials that can no be crushed fall into the crusher, spring will be out of sharp and discharge the objects.
1. When cone crusher is working, motor drives the eccentric sleeve to rotate. The eccentric sleeve drives the transmission shaft and cone part to make swing movement. When they swing to the extent that the surface of the crushing wall is close to the roll mortar wall, the rocks and ores are pressed and crushed.
2. Joint between supporting sleeve and frame is compressed by spring. When metal block and other materials that can no be crushed fall into the crusher, spring will be out of sharp and discharge the objects.
3. When the materials that can not be crushed pass through the crushing chamber or the machine overloads, the spring safety system makes the cone discharging hole become larger. When objects are discharged from crushing chamber, discharging hole will automatically reset. Cone crusher resumes normal operations.
4. The surface of crushing chamber is covered with wear-resisting high manganese steel lining plate. Size of discharging hole can be adjusted hydraulically or manually.
Note: for information purposes only, any questions please contact us!
Address: Xigang Industrial Area,Zhengshang Road, Zheng zhou,Henan Province, China
Tel :0371 -67,826,860
